HGW1 SCR Power Regulator for Transformer
HGW1 Series Single-Phase Inductive Load Thyristor Power Regulator
◎ Adopts pure analog circuit design, highly resistant to interference and highly reliable.
◎ Synchronized voltage pre-wired at the factory, no need for customers to select phase.
◎ Constant current control mode provides excellent control for transformer loads.
◎ Factory-built-in transformer with optional external transformer for secondary current control feedback.
| Part Numbers | *1-*2-*3-*4-*5 | e.g. | HGW1-1-4-060-P |
| Description | Code | Value | |
| *1 | Design Code | HGW1 | |
| *2 | Phase | 1 | Single phase |
| *3 | Main Power Supply | 2 | 220V |
| 4 | 380V | ||
| *4 | Rated Current | 030 | 30A |
| 060 | 60A | ||
| ... | ... | ||
| 200 | 200A | ||
| *5 | Control mode setting | P | Phase open-loop control |
| C | Phase constant current |
| Model | Rated current |
Load (KW) | Product size (mm) |
Mount size(mm) |
Weight (kg) |
Screw | Torque | Cooling method | ||||
| 220V | 380V | L | W | H | L | W | ||||||
| HGW1-1-4-060-P | 60A | 10 | 15 | 250 | 140 | 195 | 162 | 135 | 3 | M6 | 50kgfcm | Forced air cooling |
| HGW1-1-4-080-P | 80A | 15 | 25 | 250 | 140 | 195 | 162 | 135 | 3 | M6 | 50kgfcm | Forced air cooling |
| HGW1-1-4-100-P | 100A | 18 | 30 | 250 | 140 | 195 | 162 | 135 | 3 | M6 | 50kgfcm | Forced air cooling |
| HGW1-1-4-125-P | 125A | 22 | 36 | 250 | 140 | 195 | 162 | 135 | 3.5 | M8 | 80kgfcm | Forced air cooling |
| HGW1-1-4-150-P | 150A | 26 | 44 | 250 | 140 | 195 | 162 | 135 | 3.5 | M8 | 80kgfcm | Forced air cooling |
| HGW1-1-4-175-P | 175A | 30 | 50 | 250 | 140 | 195 | 162 | 135 | 3.5 | M8 | 80kgfcm | Forced air cooling |
| HGW1-1-4-200-P | 200A | 35 | 60 | 250 | 140 | 195 | 162 | 135 | 3.5 | M8 | 80kgfcm | Forced air cooling |
Need more information?
Contact us to request pricing, availability and customization options.
