SSR dc to dc 150A 200V
Home Products DC Solid State Relays 120A to 2000A200V DC SSRSSR dc to dc 150A 200V
Product details
SSR dc to dc 150A 200V
| Name | DC to DC Solid state relay | DC to DC Solid state relay | DC to DC Solid state relay | DC to DC Solid state relay |
| Type | Standard | Standard | Standard | Fast switching |
| Part numbers | GDZ08-150200D1 | GDZ08-150200D2 | GDZ08-150200D4 | GDZ08C-150200D3 |
| Control voltage | 12-15VDC | 18-36VDC | 12-60VDC | 4-32VDC |
| Control power supply | / | / | / | 12/24VDC |
| Max.switching current per phase | 150A | 150A | 150A | 150A |
| Max.switching voltage | 0-200VDC | 0-200VDC | 0-200VDC | 0-200VDC |
| Switching time | ≤1mS | ≤1mS | ≤5mS | ≤0.08mS |
| Output method | Mosfet DC output | Mosfet DC output | Mosfet DC output | Mosfet DC output |
| Mounting | Panel mount | Panel mount | Panel mount | Panel mount |
| Contacts configuration | 1NO | 1NO | 1NO | 1NO |
| Manufacturer | Greegoo | Greegoo | Greegoo | Greegoo |
| Certificates | CE, RoHS | CE, RoHS | CE, RoHS | CE, RoHS |
| Note | Part numbers with "L" for over current protection, e.g. GDZ08-150200D2L, Part numbers with "T" for over temperature protection, e.g. GDZ08-150200D2T | |||
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
