Single thyristor module MT200A/250A/300A
Home Products Thyristor Diode ModuleSingle Thyristor ModuleSingle thyristor module MT200A/250A/300A
Product Details
Single thyristor module MT200A/250A/300A
| Type | IT(AV) | VDRM VRRM | VTM@ITM | IDRM IRRM | IGT | VGT | IH | dV/dt | di/dt | ITSM | Rjc | Tjm | Viso | Outline | |
| A | V | V | A | mA | mA | V | mA | V/μs | A/μs | A×103 | ℃/W | ℃ | V(AC) | ||
| MT200A | 200 | 400-2600 | 1.9 | 600 | 30 | 180 | 2.5 | 100 | 800 | 100 | 7.2 | 0.14 | 125 | 2500 | M28 |
| MT250A | 250 | 400-2600 | 1.73 | 750 | 30 | 180 | 2.5 | 100 | 800 | 100 | 8.5 | 0.12 | 125 | 2500 | M28 |
| MT300A | 300 | 400-2600 | 1.58 | 900 | 40 | 180 | 2.5 | 100 | 800 | 100 | 9.3 | 0.1 | 125 | 2500 | M28 |
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
