Phase Control Thyristor T151
Home Products Stud Screw Fit ThyristorStud Thyristor (Russian version)Phase Control Thyristor T151
Product Details
Phase Control Thyristor T151
| Type | VDRM | IT(AV) | ITSM | VTM /ITM | V T(TO) | rT | (diT/ | duD/dt) cr | t q(typ) | R th(j-c) | TVJM | Md | Case |
| VRRM | dt)cr | ||||||||||||
| (TC,ºC) | 10ms | TVJM | TVJM | TVJM | TVJM | TVJM | |||||||
| V | A | kA | V/A | V | mΩ | A/μs | V/μs | μs | ºC/W | ºC | Nm | ºC/W | |
| T151-100 | 300-1800 | 100(90) | 2 | 1.80/314 | 1.15 | 2.4 | 160 | 200-1000 | 160 | 0.3 | 140 | 10-20 | ST5 |
