Magnetic Motor Starter(E3RV)
| Standard power ratings of 3-phase motors 50/60Hz in category AC-3 (kW) | Setting range of thermal trips (A) | Magnetic tripping current (A) | Thermal current Ie in (A) | Short circuit breaking capacity under the condition of AC 400V | Reference |
| 0.04 | 0.11-0.16 | 2.1 | 0.16 | 100 | E3RV10 11-0AA1 |
| 0.06 | 0.14-0.2 | 2.6 | 0.2 | 100 | E3RV10 11-0BA1 |
| 0.06 | 0.18-0.25 | 3.3 | 0.25 | 100 | E3RV10 11-0CA1 |
| 0.09 | 0.22-0.32 | 4.2 | 0.32 | 100 | E3RV10 11-0DA1 |
| 0.09 | 0.28-0.4 | 5.2 | 0.4 | 100 | E3RV10 11-0EA1 |
| 0.12 | 0.35-0.5 | 6.5 | 0.5 | 100 | E3RV10 11-0FA1 |
| 0.18 | 0.45-0.63 | 8.2 | 0.63 | 100 | E3RV10 11-0GA1 |
| 0.18 | 0.55-0.8 | 10 | 0.8 | 100 | E3RV10 11-0HA1 |
| 0.25 | 0.7-1 | 13 | 1 | 100 | E3RV10 11-0JA1 |
| 0.37 | 0.9-1.25 | 16 | 1.25 | 100 | E3RV10 11-0KA1 |
| 0.55 | 1.1-1.6 | 21 | 1.6 | 100 | E3RV10 11-1AA1 |
| 0.75 | 1.4-2 | 26 | 2 | 100 | E3RV10 11-1BA1 |
| 0.75 | 1.8-2.5 | 33 | 2.5 | 100 | E3RV10 11-1CA1 |
| 1.1 | 2.2-3.2 | 42 | 3.2 | 100 | E3RV10 11-1DA1 |
| 1.5 | 2.8-4 | 52 | 4 | 100 | E3RV10 11-1EA1 |
| 1.5 | 3.5-5 | 65 | 5 | 100 | E3RV10 11-1FA1 |
| 2.2 | 4.5-6.3 | 82 | 6.3 | 100 | E3RV10 11-1GA1 |
| 3 | 5.5-8 | 104 | 8 | 50 | E3RV10 11-1HA1 |
| 4 | 7-10 | 130 | 10 | 50 | E3RV10 11-1JA1 |
| 5.5 | 9-12 | 156 | 12 | 50 | E3RV10 11-1KA1 |
| 0.04 | 0.11-0.16 | 2.1 | 0.16 | 100 | E3RV10 21-0AA1 |
| 0.06 | 0.14-0.2 | 2.6 | 0.2 | 100 | E3RV10 21-0BA1 |
| 0.06 | 0.18-0.25 | 3.3 | 0.25 | 100 | E3RV10 21-0CA1 |
| 0.09 | 0.22-0.32 | 4.2 | 0.32 | 100 | E3RV10 21-0DA1 |
| 0.09 | 0.28-0.4 | 5.2 | 0.4 | 100 | E3RV10 21-0EA1 |
| 0.12 | 0.35-0.5 | 6.5 | 0.5 | 100 | E3RV10 21-0FA1 |
| 0.18 | 0.45-0.63 | 8.2 | 0.63 | 100 | E3RV10 21-0GA1 |
| 0.18 | 0.55-0.8 | 10 | 0.8 | 100 | E3RV10 21-0HA1 |
| 0.25 | 0.7-1 | 13 | 1 | 100 | E3RV10 21-0JA1 |
| 0.37 | 0.9-1.25 | 16 | 1.25 | 100 | E3RV10 21-0KA1 |
| 0.55 | 1.1-1.6 | 21 | 1.6 | 100 | E3RV10 21-1AA1 |
| 0.75 | 1.4-2 | 26 | 2 | 100 | E3RV10 21-1BA1 |
| 0.75 | 1.8-2.5 | 33 | 2.5 | 100 | E3RV10 21-1CA1 |
| 1.1 | 2.2-3.2 | 42 | 3.2 | 100 | E3RV10 21-1DA1 |
| 1.5 | 2.8-4 | 52 | 4 | 100 | E3RV10 21-1EA1 |
| 1.5 | 3.5-5 | 65 | 5 | 100 | E3RV10 21-1FA1 |
| 2.2 | 4.5-6.3 | 82 | 6.3 | 100 | E3RV10 21-1GA1 |
| 3 | 5.5-8 | 104 | 8 | 100 | E3RV10 21-1HA1 |
| 4 | 7-10 | 130 | 10 | 100 | E3RV10 21-1JA1 |
| 5.5 | 9-12.5 | 163 | 12.5 | 100 | E3RV10 21-1KA1 |
| 7.5 | 11-16 | 208 | 16 | 50 | E3RV10 21-4AA1 |
| 7.5 | 14-20 | 260 | 20 | 50 | E3RV10 21-4BA1 |
| 11 | 17-22 | 286 | 22 | 50 | E3RV10 21-4CA1 |
| 11 | 20-25 | 325 | 25 | 50 | E3RV10 21-4DA1 |
