Fast Recovery Diode Module (Korea package)
Home Products IGBT Power ModuleFast Recovery Diode ModulesFast Recovery Diode Module (Korea package)
Fast Recovery Diode Module (Korea package)
Our FRDs from 400V to 1200V in both isolated and non-isolated (FD3) housings. The power module are ideally suited for applications requiring fast switching and soft recovery for low EMI/RFI.
600V FRD modules
|
FD2 |
GA300BN60K |
600 |
300x1 |
1.2 |
180 |
15.0 |
SS |
|
FD3 |
GB100NH60S |
600 |
100x2 |
1.3 |
140 |
1.0 |
NH |
|
GB150NH60S |
600 |
150x2 |
1.3 |
120 |
1.0 |
NH |
|
|
FD4 |
GC100NC60S |
600 |
100x2 |
1.3 |
140 |
1.0 |
NC |
|
GC100PC60S |
600 |
100x2 |
1.3 |
140 |
1.0 |
PC |
|
|
GC100NC60K |
009 |
100x2 |
1.2 |
140 |
1.0 |
NC |
|
|
GC100NS60K |
009 |
100x2 |
1.2 |
140 |
1.0 |
NS |
|
|
GC100PC60K |
600 |
100x2 |
1.2 |
140 |
1.0 |
PC |
|
|
GC100PS60K |
600 |
100x2 |
1.2 |
140 |
1.0 |
PS |
|
|
GC150NC60K |
600 |
150x2 |
1.3 |
150 |
1.0 |
NC |
|
|
GC150PC60K |
009 |
150x2 |
1.3 |
150 |
1.0 |
PC |
|
|
FD5 |
GD150NC60K |
600 |
150x2 |
1.3 |
150 |
1.0 |
NC |
|
GD150NS60K |
600 |
150x2 |
1.3 |
150 |
1.0 |
NS |
|
|
GD150PC60K |
600 |
150x2 |
1.3 |
150 |
1.0 |
PC |
|
|
GD150PS60K |
600 |
150x2 |
1.3 |
150 |
1.0 |
PS |
|
|
GD200NC60K |
600 |
200x2 |
1.3 |
160 |
6.0 |
NC |
|
|
GD200NS60K |
600 |
200x2 |
1.3 |
160 |
6.0 |
NS |
|
|
GD200PC60K |
600 |
200x2 |
1.3 |
160 |
6.0 |
PC |
|
|
GD200PS60K |
600 |
200x2 |
1.3 |
160 |
6.0 |
PS |
|
|
GD300NC60K |
600 |
300x2 |
1.35 |
200 |
15.0 |
NC |
|
|
GD300PC60K |
600 |
300x2 |
1.35 |
200 |
15.0 |
PC |
|
|
FD5 |
GD300SS60K |
600 |
300x1 |
1.35 |
200 |
15.0 |
SS |
|
FD6 |
GE60FB60S |
600 |
60x4 |
1.25 |
140 |
1.0 |
FB |
|
GE80FB60S |
600 |
80x4 |
1.25 |
140 |
1.0 |
FB |
|
|
GE100FB60K |
600 |
100x4 |
1.2 |
140 |
1.0 |
FB |
|
|
FD8 |
GM300NC60K |
600 |
600x2 |
1.35 |
200 |
15.0 |
NC |
400V FRD modules
|
Package |
Part No |
VRRM [V] |
IF [A] @100℃ |
VF [V] @25℃ |
trr [ns] @25℃ |
Irrm [mA] @25℃ |
Circuit |
|
FD3 |
GB100NH40S |
400 |
100x2 |
1.05 |
90 |
1.0 |
NH |
|
GB150NH40S |
400 |
150x2 |
1.05 |
100 |
1.0 |
NH |
|
|
GB200NH40S |
400 |
200x2 |
1.05 |
150 |
1.0 |
NH |
|
|
FD4 |
GC100NC40SE |
400 |
100x2 |
1.05 |
90 |
1.0 |
NC |
|
GC100NC40S |
400 |
100x2 |
1.05 |
90 |
1.0 |
NC |
|
|
GC100NS40S |
400 |
100x2 |
1.05 |
90 |
1.0 |
NS |
|
|
GC160NC40SE |
400 |
160x2 |
1.10 |
100 |
1.0 |
NC |
|
|
FD5 |
GD150NC40S |
400 |
150x2 |
1.05 |
100 |
1.0 |
NC |
|
GD150NS40S |
400 |
150x2 |
1.05 |
100 |
1.0 |
NS |
|
|
GD200NC40S |
400 |
200x2 |
1.05 |
150 |
1.0 |
NC |
|
|
GD200NS40S |
400 |
200x2 |
1.05 |
150 |
1.0 |
NS |
1200V FRED modules
|
FD4 |
GC75NVC120S |
1200 |
75x2 |
2.15 |
125 |
3.0 |
NC |
|
GC75NS120S |
1200 |
75x2 |
2.15 |
125 |
3.0 |
NS |
|
|
GC75PC120S |
1200 |
75x2 |
2.15 |
125 |
3.0 |
PC |
|
|
GC75PS120S |
1200 |
75x2 |
2.15 |
125 |
3.0 |
Sd |
|
|
GC100NC120S |
1200 |
100x2 |
1.6 |
180 |
2.0 |
NC |
|
|
GC100NS120S |
1200 |
100x2 |
1.6 |
180 |
2.0 |
NS |
|
|
GC100PC120S |
1200 |
100x2 |
1.6 |
180 |
2.0 |
PC |
|
|
GC100PS120S |
1200 |
100x2 |
1.6 |
180 |
2.0 |
PS |
|
|
FD5 |
GD150NC120S |
1200 |
150x2 |
2.2 |
190 |
6.0 |
NC |
|
GD150PC120S |
1200 |
150x2 |
2.2 |
190 |
6.0 |
PC |
|
|
GD150NS120S |
1200 |
150x2 |
2.2 |
190 |
6.0 |
NS |
|
|
GD150PS120S |
1200 |
150x2 |
2.2 |
190 |
6.0 |
PS |
|
|
GD200NC120S |
1200 |
200x2 |
1.65 |
310 |
9.0 |
NC |
|
|
GD200PC120S |
1200 |
200x2 |
1.65 |
310 |
9.0 |
PC |
Circuit
Package
Need more information?
Contact us to request pricing, availability and customization options.
FRED modules
300A/400A 1200V and 1700V fred modules.
View More
Fast Diode Module SKKD150F12 SKMD150F12 SKND150F12
SKKD150F12 SKMD150F12 SKND150F12 FAST DIODE MODULE
View More
FRED modules
2x100,2x150,2x200A 600V, 700V and 1200V fred module.
View More
FRED Fast Recovery Epitaxial Diode Module
75A to 800A @ 600V or 1200V FRED modules
