3 phase digital scr controller 175A
Home Products SCR Power ControllerHGW6 dual Digital type3 phase digital scr controller 175A
3 phase digital scr controller 175A
◎ Adopts 32-bit MCU dual-core control with PID closed-loop control for 100% linear output.
◎ Dual-row digital display with freely definable display of input, output, voltage, current, and power.
◎ Dual-channel input signal design with direct switching between current and voltage.
◎ Fast-acting fuse combined with transformer for dual overcurrent protection.
◎ Parameter storage and one-key reset function.
◎ MODBUS RTU communication.
| Model | Phase | Input Voltage | Rated Current |
Load Power(KW) | Weight (Kg) |
Control mode | Control signal | |
| 220V | 380V | |||||||
| HGW6-4-4-175-P | 3Ph | 380-440V | 175A | 53 | 88 | 6 | Phase angle (constant voltage limiting current) | 4-20mA/0-5V |
| HGW6-4-4-175-C | 3Ph | 380-440V | 175A | 53 | 88 | 6 | Phase angle constant current | 4-20mA/0-5V |
| HGW6-4-4-175-CV | 3Ph | 380-440V | 175A | 53 | 88 | 6 | Phase angle constant power | 4-20mA/0-5V |
| HGW6-4-4-175-Z | 3Ph | 380-440V | 175A | 53 | 88 | 6 | Zero crossing cycle power regulating | 4-20mA/0-5V |
| HGW6-4-2-175-P | 3Ph | 110-220V | 175A | 53 | 88 | 6 | Phase angle (constant voltage limiting current) | 4-20mA/0-5V |
| HGW6-4-2-175-C | 3Ph | 110-220V | 175A | 53 | 88 | 6 | Phase angle constant current | 4-20mA/0-5V |
| HGW6-4-2-175-CV | 3Ph | 110-220V | 175A | 53 | 88 | 6 | Phase angle constant power | 4-20mA/0-5V |
| HGW6-4-2-175-Z | 3Ph | 110-220V | 175A | 53 | 88 | 6 | Zero crossing cycle power regulating | 4-20mA/0-5V |
Need more information?
Contact us to request pricing, availability and customization options.
3 phase digital scr controller 30A and 40A with cooling fan
30A/40A three phase dual digital display, 110-220V/330-440VAC, with cooling fan
3 phase digital scr controller 50A to 80A
50A/60A/75A/80A three phase dual digital display, 110-220V/330-440VAC
Single phase digital scr controller 125A to 200A
125A/150A/175A/200A single phase single digital display 110-220V/330-440VAC
3 phase digital scr controller 200A
200A three phase dual digital display, 110-220V/330-440VAC
