3 phase SCR Regulator for Transformer and Inductive Load
HGW1 Series Three-Phase Inductive Load Dedicated Thyristor Power Regulator
Product Features
Adopts pure analog circuit design, high anti-interference capability, high reliability
Soft start and soft shutdown functions, low inrush current
Constant current control method provides excellent control effect for transformer loads
All series built-in three-phase mutual inductors, 10 ms hardware overcurrent protection device
| Part Numbers | *1-*2-*3-*4-*5 | e.g. | HGW1-4-4-060-C |
| Description | Code | Value | |
| *1 | Design Code | HGW1 | |
| *2 | Phase | 4 | Three phase |
| *3 | Main Power Supply | 2 | 220V |
| 4 | 380V | ||
| *4 | Rated Current | 060 | 60A |
| 080 | 80A | ||
| ... | ... | ||
| 400 | 400A | ||
| C | Phase constant current |
| Model | Rated | load(KW) | Product | Mount | Weight | Screw | Torque | ||||
| current | size (mm) | size(mm) | (kg) | ||||||||
| 220V | 380V | L | W | H | L | W | |||||
| HGW1-4-4-060-C | 60A | 19 | 33 | 325 | 164 | 208 | 316 | 104 | 6 | M8 | 50kgfcm |
| HGW1-4-4-080-C | 80A | 25 | 44 | 325 | 164 | 208 | 316 | 104 | 6 | M8 | 75kgfcm |
| HGW1-4-4-100-C | 100A | 32 | 55 | 325 | 164 | 208 | 316 | 104 | 6 | M8 | 85kgfcm |
| HGW1-4-4-125-C | 125A | 40 | 68 | 325 | 164 | 208 | 316 | 104 | 10 | M8 | 95kgfcm |
| HGW1-4-4-150-C | 150A | 45 | 75 | 325 | 164 | 208 | 316 | 104 | 10 | M8 | 100kgfcm |
| HGW1-4-4-175-C | 175A | 53 | 88 | 325 | 164 | 208 | 316 | 104 | 11 | M8 | 120kgfcm |
| HGW1-4-4-200-C | 200A | 58 | 100 | 420 | 263 | 260 | 402 | 160 | 13 | M10 | 200kgfcm |
| HGW1-4-4-225-C | 225A | 65 | 110 | 420 | 263 | 260 | 402 | 160 | 13 | M10 | 200kgfcm |
| HGW1-4-4-250-C | 250A | 73 | 125 | 420 | 263 | 260 | 402 | 160 | 13 | M10 | 220kgfcm |
| HGW1-4-4-300-C | 300A | 87 | 150 | 420 | 263 | 260 | 402 | 160 | 15 | M10 | 250kgfcm |
| HGW1-4-4-350-C | 350A | 100 | 177 | 435 | 263 | 290 | 416 | 160 | 18 | M10 | 250kgfcm |
| HGW1-4-4-400-C | 400A | 115 | 200 | 435 | 263 | 290 | 416 | 160 | 22 | M10 | 250kgfcm |
Cooling Method: Forced Air Cooling
