Single Phase Bridge Rectifier GBPC-W
GBPC1506W GBPC1508W GBPC1510W, GBPC2506W, GBPC2508W, GBPC2510W, GBPC3506W, GBPC3508W, GBPC3510W, GBPC5006W, GBPC5008W, GBPC5010W
|
TYPE |
Repetitive Peak Reverse Voltage |
Maximum Average Rectified
Current
|
Maximum Forward Peak Surge Current |
Maximum Forward
Voltage
|
Maximum Reverse
Current
|
Junction Temperature |
Insulating Voltage |
|||
|
VRRM |
IF(AV)@Tc |
IFSM |
VF@IF |
IRRM@TA |
TJM |
VISO |
||||
|
(V) |
(A) |
(℃) |
(A) |
(V) |
(A) |
25℃(μA) |
125℃ (μA) |
(℃) |
(V) |
|
|
GBPC1506W |
600 |
15 |
85 |
250 |
1.1 |
7.5 |
5 |
500 |
150 |
2500 |
|
GBPC1508W |
800 |
15 |
85 |
250 |
1.1 |
7.5 |
5 |
500 |
150 |
2500 |
|
GBPC1510W |
1000 |
15 |
85 |
250 |
1.1 |
7.5 |
5 |
500 |
150 |
2500 |
|
GBPC2506W |
600 |
25 |
85 |
300 |
1.1 |
12.5 |
5 |
500 |
150 |
2500 |
|
GBPC2508W |
800 |
25 |
85 |
300 |
1.1 |
12.5 |
5 |
500 |
150 |
2500 |
|
GBPC2510W |
1000 |
25 |
85 |
300 |
1.1 |
12.5 |
5 |
500 |
150 |
2500 |
|
GBPC3506W |
600 |
35 |
85 |
400 |
1.1 |
17.5 |
5 |
500 |
150 |
2500 |
|
GBPC3508W |
800 |
35 |
85 |
400 |
1.1 |
17.5 |
5 |
500 |
150 |
2500 |
|
GBPC3510W |
1000 |
35 |
85 |
400 |
1.1 |
17.5 |
5 |
500 |
150 |
2500 |
|
GBPC5006W |
600 |
50 |
85 |
500 |
1.1 |
25 |
5 |
500 |
150 |
2500 |
|
GBPC5008W |
800 |
50 |
85 |
500 |
1.1 |
25 |
5 |
500 |
150 |
2500 |
|
GBPC5010W |
1000 |
50 |
85 |
500 |
1.1 |
25 |
5 |
500 |
150 |
2500 |
