LMZK-10-120 Split Core Current Transformer
Home Products Voltage & Current TransformerBushing Current TransformerLMZK-10-120 Split Core Current Transformer
Overview
LMZK-10-120 Split Core Current Transformer
Power factor：COCφ=0.8
Frequency：50Hz or 60Hz
Anti-Pollution grade：Glass II
Ambient temperature：-5℃ -40℃, daily average temperature not more than 30℃
Altitude：≤1000m
Product Details
| Model | Application |
Rated
secondary
current
|
Measuring CT | Protection CT | Double winding CT | ||||||
| Rated primary current |
Accuracy & rated
capacity VA |
Accuracy & rated
capacity VA |
Accuracy & rated
capacity VA |
||||||||
| 0.5 | 1 | 3 | 10P5 | 10P10 | 0.5 | 1 | 10P10 | 10P5 | |||
| LMZK-10-120 | 50 |
5A
1A
|
/ | / | 2.5 | / | / | / | / | / | / |
| 75 | / | / | 2.5 | / | / | / | / | / | / | ||
| 100 | / | 2.5 | / | 2.5 | / | / | / | / | / | ||
| 150 | / | 2.5 | / | 3.75 | 1.5 | / | / | / | / | ||
| 200 | 2.5 | 2.5 | / | 5 | 2.5 | / | / | / | / | ||
| 300 | 2.5 | 2.5 | / | 5 | 2.5 | / | 2.5 | / | 1.5 | ||
| 400 | 5 | 5 | / | 5 | 2.5 | 2.5 | 2.5 | / | 2.5 | ||
| 500 | 5 | 5 | / | 5 | 2.5 | 2.5 | 2.5 | / | 2.5 | ||
| 600 | 5 | 5 | / | 5 | 2.5 | 2.5 | 2.5 | / | 2.5 | ||
