3 Phase Digital Thyristor Controller 175A
Home Products SCR Power ControllerHGW5 single digital type3 Phase Digital Thyristor Controller 175A
3 Phase Digital Thyristor Controller 175A
Product Features
◎ Utilizes MCU embedded microcontroller control technology and PID closed-loop control for 100% linear output.
◎ Three-phase full-control 6-pulse output, compatible with transformer loads or loads with neutral wire connection.
◎ Dual-channel input signal design: 0~5V, 0~10V, 4~20mA, or potentiometer limit, with direct switching.
◎ Fast-acting fuse combined with electronic transformer for dual overcurrent protection.
◎ Digital display for input, output, current, voltage, power, with one-key switching.
| Part Numbers | Phase | Input voltage | Current | Load Power (KW) |
Weight (kg) |
Control mode | |
| 220V | 380V | ||||||
| HGW5-4-4-175-P | 3PH | 380-440V | 175A | 40 | 68.5 | 4.4 | Phase angle (constant voltage limiting current) |
| HGW5-4-4-175-Z | 3PH | 380-440V | 175A | 40 | 68.5 | 4.4 | Zero crossing (Power regulating) |
| HGW5-4-2-175-P | 3PH | 110-220V | 175A | 40 | 68.5 | 4.4 | Phase angle (constant voltage limiting current) |
| HGW5-4-2-175-Z | 3PH | 110-220V | 175A | 40 | 68.5 | 4.4 | Zero crossing (Power regulating) |
Selectable inputs: 0-5V, 0-10V, 4-20mA, or potentiometer with limiting function.
